Porsche 914/4 2.0
See specifications below illustration
Page 245
Porsche 914 4 2.0 1969-76 specifications
Engine (Boxer 4): All aluminium, 4 Cylinder, horizontally mounted, OHV, 8 valves

Bore & stroke: 93mm x 66mm

Displacement: 1,971cc

Compression ratio: 8.0 to 1

Fuel: petrol, fuel injection

Maximum speed: 190km/h (118mph)

Acceleration 0-96.5km/h, 0-60mph: 8.3sec)

Max power: 99bhp at 5,000rpm

Max torque: 157Nm at 3.400rpm

Construction: Pressed steel monocoque

Ave. fuel consumption: 25.6mpg

Transmission: 5 speed manual, mid engined, rear wheel drive

Brakes: Solid discs, F:281mm R: 282mm

Suspension: Ind. coil and trailing arms torsion bars, rear Coil

Steering: Rack & pinion

Dimensions

Turning circle: 10.m (32.5ft)

Wheels: 15in, 4 stud

Tyres: 165x80x15

Wheelbase: 2,450mm

Track front: 1,339mm, rear: 1,380mm

Overall length: 3,985mm

Overall width: 1,650mm

Overall height: 1,220mm

Tank capacity: 85.2 litres (18.7 UK gal)

Unladen weight: 950 kg (2,094 lbs)

Production: 1968-76

Total production of all 914 1969-76: 118,978 built, Stuttgart-Zuffenhausen & Onsbrück, West Germany
