Ford Zodiac MkIII 1962-66
Ford Zodiac MkIII 1962-66 specifications
Engine
6 cylinder in-line, OHV
Displacement: 2,553cc
Bore: 82.6mm
Stroke: 79.5mm
Compression ratio: 8.5 / 1
Valves: 2 per cylinder
Carburation: single Zenith downdraught
Power output: 109bhp at 4,800rpm
Performance
Maximum speed: 100mph
0-60mph: 13.5secs
Overall fuel
consumption: 18mpg
Steering
Recirculating ball
Construction
Pressed steel monocoque
Brakes
Hydraulic, Front: disc
Rear: drums
6 cylinder in-line, OHV
Displacement: 2,553cc
Bore: 82.6mm
Stroke: 79.5mm
Compression ratio: 8.5 / 1
Valves: 2 per cylinder
Carburation: single Zenith downdraught
Power output: 109bhp at 4,800rpm
Performance
Maximum speed: 100mph
0-60mph: 13.5secs
Overall fuel
consumption: 18mpg
Steering
Recirculating ball
Construction
Pressed steel monocoque
Brakes
Hydraulic, Front: disc
Rear: drums
Transmission
4 speed manual
Optional overdrive
Rear wheel drive
Suspension
Front: Independent MacPherson strut,
anti-roll bar
Rear: Semi-elliptic leaf springs
Wheels
4 stud, 13in pressed steel
6.40 x 13 tyres
Dimensions & Weight
Wheelbase: 8ft 11in
Front track: 4ft 5in
Rear track: 4ft 4in
Overall length: 15ft 2in
Overall width: 5ft 9in
Overall height: 4ft 9.5in
Kerb weight: 24.8cwt
Ground clearance: 6.8in
Zodiac MkIII Production
1961-66, Dagenham: 77,709
4 speed manual
Optional overdrive
Rear wheel drive
Suspension
Front: Independent MacPherson strut,
anti-roll bar
Rear: Semi-elliptic leaf springs
Wheels
4 stud, 13in pressed steel
6.40 x 13 tyres
Dimensions & Weight
Wheelbase: 8ft 11in
Front track: 4ft 5in
Rear track: 4ft 4in
Overall length: 15ft 2in
Overall width: 5ft 9in
Overall height: 4ft 9.5in
Kerb weight: 24.8cwt
Ground clearance: 6.8in
Zodiac MkIII Production
1961-66, Dagenham: 77,709
