See specifications below illustration TRIUMPH page
Page 086A
Specifications
Engine: 4 cylinder in-line, OHV, ?Iron block with aluminium head
Valves: 8, overhead cam
Bore & Stroke: 73.7mm x 76mm
Displacement: 1,296cc
Compression ratio: 8.5 to 1
Carburettor: Stromberg CD150
Power output: 61bhp at 5,000rpm
Maximum speed: 86mph
Acceleration 0-60mph: 19secs
OFC: approx 28mpg
Construction: all steel monocoque
Transmission: front wheel drive, 4-speed all sybchro manual, single dry plate clutch, final drive: 4.3
Brakes front: disk: Rear: drums Steering: rack and pinion
Wheels & Tyres: 13ins ventilated steel, 155/SR13 radials
Suspension Front: ind. coil & double wishbone with lower. Rear: Coil with semi trailing arms, shock-absorber spring unit.
Engine: 4 cylinder in-line, OHV, ?Iron block with aluminium head
Valves: 8, overhead cam
Bore & Stroke: 73.7mm x 76mm
Displacement: 1,296cc
Compression ratio: 8.5 to 1
Carburettor: Stromberg CD150
Power output: 61bhp at 5,000rpm
Maximum speed: 86mph
Acceleration 0-60mph: 19secs
OFC: approx 28mpg
Construction: all steel monocoque
Transmission: front wheel drive, 4-speed all sybchro manual, single dry plate clutch, final drive: 4.3
Brakes front: disk: Rear: drums Steering: rack and pinion
Wheels & Tyres: 13ins ventilated steel, 155/SR13 radials
Suspension Front: ind. coil & double wishbone with lower. Rear: Coil with semi trailing arms, shock-absorber spring unit.
Dimensions
Wheelbase: 8ft 0.6in
Track - front: 4ft 5in
Track - rear: 4ft 4.6in
Overall length:12ft 11in
Overall width: 5ft 1.7in
Overall height: 4ft 6in
Ground clearance: 5.5in
Fuel tank: 11.8 Imp gal.
Kerb weight: 17,55cwt
Production:1965-1970 113,008 built Coventry, England
Designed by Giovanni Michelotti
Wheelbase: 8ft 0.6in
Track - front: 4ft 5in
Track - rear: 4ft 4.6in
Overall length:12ft 11in
Overall width: 5ft 1.7in
Overall height: 4ft 6in
Ground clearance: 5.5in
Fuel tank: 11.8 Imp gal.
Kerb weight: 17,55cwt
Production:1965-1970 113,008 built Coventry, England
Designed by Giovanni Michelotti
