Sunbeam Rapier 1967-76
See specifications below illustration
Page 084
Whilst the trademark owner has consented to the reproduction of its logo and emblems it has no connection with or responsibility for this drawing or for the technical data and gives no warranty as to its accuracy.

Sunbeam Rapier 2 door, 4 seat Coupé 1967-76 specifications

Engine
Slanted 4 cylinder in line
8 valves, overhead cam
Bore: 81.5mm
Stroke: 82.5mm
Displacement: 1,725cc
Compresion ratio: 9.6:1
Carburettors: two
Power output: 105bhp at 5200rpm

Performance
Maximum speed: 106mph
Acceleration: 0-60 mph 11.1secs
Overall fuel consumption
approx: 24.3mpg

Construction
All steel monocoque

Transmission
Manual with overdrive
Rear wheel drive
Clutch: single dry plate
Gearbox: 6 forward speeds

Brakes
Front: disc
Rear: drum
Power assisted

Steering
Recirculating ball

Suspension
Front: independant coil and wishbones, anti roll bar
Rear: semi eliptic leaf
Telescopic dampers

Wheels & Tyres
13ins ventilated Rostyle
165/80HR13 radials tyres

Dimensions & Capacaties
Wheelbase: 98.5in
Track - front: 51.8in
Track - rear: 51.8in
Overall length:174.5in
Overall width: 64.7in
Overall height: 55in
Ground clearance: 5in
Fuel tank capacity: 15 gallons
Kerb weight: 2305 lbs

Production
1967-76 42,606 produced
