Stanbury TT (Triumph) 1982-92

See specifications and enlarged front view below illustration

Triumph Stanbury TT specifications
The Stanbury TT was a kit car using a Triumph Herald or Spitfire as donor vehicle

Production
1982-92: 7

PDD 270G specifications:
Engine
OHV 4 Cylinder in line
Bore: 73.7mm
Stroke: 76mm
Displacement: 1,296cc
Compression ratio: 9 :1
Carburettors: Twin SU HS2
Power output: 63bhp at 6,000rpm

Transmission
Clutch: Borg & Beck single dry plate
Gearbox: 4-speed, all synchromesh, D type overdrive optional Final drive ratio: 3.89:1

Wheels
Centre lock 15in wire

Suspension
Front: upper and lower wishbones,
coil springs, anti roll bar
Rear: independent, swing axle radius arms, pivoting transverse leaf spring
Telescopic dampers front & rear

Steering
Rack and pinion Turning circle: 24ft
3.5 turns lock to lock

Brakes
Front: 9in disk
Rear: 7in x 1.25in drums

Construction
Steel chassis, space tubular steelframe aluminium panels

Dimensions & Weight
Wheelbase: 6ft 11in
Track - front: 4ft 1in(2in late)
Track - rear: 4ft 1in
Overall length: 12ft 9in
Overall width: 4ft 10in
Overall height: 3ft 1.5in
Unladen weight: 12.6cwt
Tank capacity: 7.25 Imp gallons
