MG Magnette ZB Varitone 1956-58
See specifications below illustration
Engine
Cylinders: 4 inline, B Series
Bore & Stroke: 73mm x 88.9mm
Displacement: 1489 cc
Valves: Pushrod/overhead
Compression ratio: 8.3:1
Carburettors: Twin 1.5 H4 SU
Power output: 68bhp at 5400 rpm
Performance
Maximum speed: 88mph
Acceleration: 0-60 mph 18.5secs
Overall fuel consumption: 27mpg
Transmission
Clutch: 8 in Borg and Beck,
single dry-plate diaphragm
Gearbox: 4-speed, synchromesh on
2nd, 3rd and top gears
Ratios: Top 1.0, 3rd 1.374, 2nd 2.214,
1st 3.64, reverse 4.76
Propellar Shaft: Hardy Spicer open shaft, needle bearing u/j at each end
Final Drive: live axle, hypoid bevel gears
Cylinders: 4 inline, B Series
Bore & Stroke: 73mm x 88.9mm
Displacement: 1489 cc
Valves: Pushrod/overhead
Compression ratio: 8.3:1
Carburettors: Twin 1.5 H4 SU
Power output: 68bhp at 5400 rpm
Performance
Maximum speed: 88mph
Acceleration: 0-60 mph 18.5secs
Overall fuel consumption: 27mpg
Transmission
Clutch: 8 in Borg and Beck,
single dry-plate diaphragm
Gearbox: 4-speed, synchromesh on
2nd, 3rd and top gears
Ratios: Top 1.0, 3rd 1.374, 2nd 2.214,
1st 3.64, reverse 4.76
Propellar Shaft: Hardy Spicer open shaft, needle bearing u/j at each end
Final Drive: live axle, hypoid bevel gears
Body/Chassis
Unitary construction, 4 door saloon
Brakes
Lockheed 10in x 1.75in drum
Steering
Cam gears rack and pinion,
3 turns lock to lock
Suspension
Front: Independent, coil spring, wishbone Suspension
Rear: Semi elliptic, leaf spring
Wheels
4.5J x 15in bolt on
ventilated discs
Unitary construction, 4 door saloon
Brakes
Lockheed 10in x 1.75in drum
Steering
Cam gears rack and pinion,
3 turns lock to lock
Suspension
Front: Independent, coil spring, wishbone Suspension
Rear: Semi elliptic, leaf spring
Wheels
4.5J x 15in bolt on
ventilated discs
Dimensions & Weight
Wheelbase: 8ft 6in
Track - front: 4ft 3in
Track - rear: 4ft 3in
Overall length: 14ft 1in
Overall width: 5ft 3in
Height: 4 ft 10in
Ground clearance: 5.5in
Turning circle: 32ft
Kerb weight: 2,464 lb
Production
ZA(1953-1956): 12,754
ZB(1956-1959): 28,846
Wheelbase: 8ft 6in
Track - front: 4ft 3in
Track - rear: 4ft 3in
Overall length: 14ft 1in
Overall width: 5ft 3in
Height: 4 ft 10in
Ground clearance: 5.5in
Turning circle: 32ft
Kerb weight: 2,464 lb
Production
ZA(1953-1956): 12,754
ZB(1956-1959): 28,846
