Whilst the trademark owner has consented to the reproduction of its logo and emblems it has no connection with or responsibility for this drawing or for the technical data and gives no warranty as to its accuracy.

Hillman Minx IIIA 1959-61 specifications

Engine
4 Cylinders in line ohv
Bore: 79 mm
Stroke: 76.2 mm
Displacement: 1,494cc
Compression ratio: 8.5:1
Carburettors: Zenith 30 VMB downdraught

Performance
Maximum speed: 82mph
Acceleration: 0-60 mph 26.6sec
Max power: 49bhp at 4,400 rpm
Fuel consumption: 28.6mpg

Construction
All steel unitary, vynide upholstery

Brakes
Hydraulic 9in Lockheed drum all round

Transmission
Clutch: 8in Borg and Beck,
single dry-plate diaphragm
Gearbox: manual 4-speed
or optional, 3 speed Smiths ‘Easydrive’ automatic
Synchromesh on upper 3 gears
Ratios(manual): Top 4.55, 3rd 6.34,
2nd 9.75, 1st 15.24, reverse 19.31
Prop shaft: Hardy Spicer open
Final drive: Hypoid Bevel
Axle ratio 4.44:1

Steering
Burman recirculating ball

Suspension
Front: Independent, coil spring
and wishbone, telescopic shock absorbers
Rear: Semi-elliptic, leaf spring, Armstong telescopic dampers

Wheels
Bolt on disc wheels with
5.50-5.90 x 15in crossply tyres

Dimensions
Wheelbase: 8ft 0in
Track - front: 4ft 1in
Track - rear: 4ft 0.5in
Overall length: 13ft 6in
Overall width: 5ft 0.75in
Overall height: 4ft 10in
Ground clearance: 7in
Turning circle: 36ft
Unladen weight: 19.25cwt
Fuel tank capacity: 7.25gals

Minx IIIA Production
1958 to 1960
Price new in 1959: £764,
(incl. purchase tax)
