Triumph Herald Convertible 1200 1961-68
See specifications below illustration. To HERALD & VITESSE page.
Page 087J
Triumph Herald Convertible 1200 1960-67 Specifications
Engine
4 Cylinder in line
Bore: 69.3mm
Stroke: 76mm
Displacement: 1,147 cc
Compression ratio: 8.0 : 1
Carburettors: single solex B.30 PSEI
Power output: 48bhp at 5,200rpm

Performance
Maximum speed: 76mph
Acceleration: 0-60 mph 23.9secs
Overall fuel consumption: 31.7mpg

Construction
Steel body & panels bolted onto steel backbone frame

Transmission
Clutch: Borg & Beck 6.25in single
Gearbox: 4-speed, synchromesh on
top 3 gears
Ratios: Top 4.11, 3rd 5.74, 2nd 8.88, 1st & reverse 15.42
Differential ratio: 4.11

Brakes
Girling hydraulic drums front and rear

Steering
Rack and pinionTurning circle: 24ft

Suspension
Front: Independant coil and wishbone with telescopic hydraulic dampers, anti-roll bar, rear: independent with transverse leaf spring
Wheels
Bolt-on 13in Pressed steel disc
Rims: 31/2D, tyres: 520 x 13in

Dimensions & Weight
Wheelbase: 7ft 8in
Track - front: 4ft 1in
Track - rear: 4ft
Overall length: 12ft 9in
Overall width: 5ft
Overall height: 4ft 4in
Dry weight: 153/4cwt

Capacities
Fuel Tank: 6.5gals
Engine: 8 pints
Cooling: 81/2 pints

Production
Total Herald production 1959-71: 289,575
