See specifications below illustration. To HERALD & VITESSE page
Page 087L
Triumph Herald Estate 1200 1960-67 Specifications
Engine
4 Cylinder in line
Bore: 73.7mm
Stroke: 76mm
Displacement: 1,296cc
Compression ratio: 8.5/1
Carburettor: stromberg 150CD
Power output: 61bhp at 5,000rpm
max Torque 73 lb/ft at 3,000rpm

Performance
Maximum speed approx: 85mph
Acceleration: 0-60 mph 16.6secs
Overall fuel consumption: 25mpg

Construction
Steel body & panels bolted onto steel backbone frame

Transmission
Clutch: Borg & Beck 6.25in single
Gearbox: 4-speed, synchromesh on
top 3 gears
Ratios: Top 4.11, 3rd 5.74, 2nd 8.88, 1st & reverse 15.42
Differential ratio: 4.11

Brakes
Girling hydraulic drums front and rear

Steering
Rack and pinion
4.4 turns lock to lock
Turning circle: 25ft
Suspension
Front: Independant coil and wishbone with telescopic hydraulic dampers, anti-roll bar, rear: independent with transverse leaf spring
Dimensions & Weight
Wheelbase: 7ft 8in
Track - front: 4ft 1in
Track - rear: 4ft
Ground clearance: 6.7in
Overall length: 12ft 9in
Overall width: 5ft
Overall height: 4ft 4in
Kerb weight: 17cwt

Capacities
Fuel Tank: 6.5gals
Engine: 8 pints
Cooling: 81/2 pints

Production
Herald 1200, 1960-67
Total Herald production ?1959-71: 289,575
