Austin Healey 3000 Mkll convertible 1962-64
(more curved windscreen, twin carbs, fold down hood)
See copiable specifications below illustration
Austin Healey 3000 Mkll contvertible 1962-64 specifications
(curved windscreen, twin carbs, fold down hood
(curved windscreen, twin carbs, fold down hood
Engine
OHV 6 Cylinder in line
Bore: 83mm
Stroke: 88mm
Displacement: 2,912cc
Compression ratio: 9:1
Carburettors: twin SU
Power output: 132bhp at 4700rpm
Performance
Maximum speed: 116 mph
Acceleration: 0-60 mph 9.8secs
OHV 6 Cylinder in line
Bore: 83mm
Stroke: 88mm
Displacement: 2,912cc
Compression ratio: 9:1
Carburettors: twin SU
Power output: 132bhp at 4700rpm
Performance
Maximum speed: 116 mph
Acceleration: 0-60 mph 9.8secs
Construction
Pressed steel box section frame welded to all metal body
Brakes
Hyraulic Girling
Front: 11in disk, Rear: 11in drums
Suspension
Front: Independent coil and wishbones
Rear: Live axle, half-eleptic springs
Pressed steel box section frame welded to all metal body
Brakes
Hyraulic Girling
Front: 11in disk, Rear: 11in drums
Suspension
Front: Independent coil and wishbones
Rear: Live axle, half-eleptic springs
Wheels
Bolt-on wire 15in wheels
with 5.5 x 15in crossply tyres
Dimensions & Weight
Wheelbase: 7ft 8in
Track - front: 4ft
Track - rear: 4ft 1in
Overall length: 13ft 1in
Overall width: 5ft
Unladen weight: 20.5cwt
Production
MkII 1961-62: 5,450
MkII Convertible 1962-64: 6,113
Bolt-on wire 15in wheels
with 5.5 x 15in crossply tyres
Dimensions & Weight
Wheelbase: 7ft 8in
Track - front: 4ft
Track - rear: 4ft 1in
Overall length: 13ft 1in
Overall width: 5ft
Unladen weight: 20.5cwt
Production
MkII 1961-62: 5,450
MkII Convertible 1962-64: 6,113
