Ford Escort Mk1 2dr 1968-74
See specifications below illustration
Ford Escort Mk1 2dr 1968-74 Specifications
Engine
4 cylinder in-line, OHV
Crankshaft bearings: 5
Displacement: 1,297cc
Bore: 81mm
Stroke: 63 mm
Compression ratio: 9.0 - 1
Valves: 2 per cylinder
Carburettors: one
Power output: 57 bhp at 5,500rpm
Performance
Maximum speed: 85mph
Acceleration: 0-60 mph 17.6secs
Overall fuel consumption: 26.7mpg
4 cylinder in-line, OHV
Crankshaft bearings: 5
Displacement: 1,297cc
Bore: 81mm
Stroke: 63 mm
Compression ratio: 9.0 - 1
Valves: 2 per cylinder
Carburettors: one
Power output: 57 bhp at 5,500rpm
Performance
Maximum speed: 85mph
Acceleration: 0-60 mph 17.6secs
Overall fuel consumption: 26.7mpg
Transmission
4-speed manual, all syncromesh
Rear wheel drive
Construction
Pressed steel monocoque
Brakes
Hydraulic, Front: discs Rear: drum
Steering
Rack and pinion,
Suspension
Front: Independent MacPherson strut,
anti roll bar
Rear: Semi-elliptic leaf springs
4-speed manual, all syncromesh
Rear wheel drive
Construction
Pressed steel monocoque
Brakes
Hydraulic, Front: discs Rear: drum
Steering
Rack and pinion,
Suspension
Front: Independent MacPherson strut,
anti roll bar
Rear: Semi-elliptic leaf springs
Wheels
4 stud, 12in, pressed steel
Dimensions & Weight
Wheelbase: 7ft 10.5in
Track: 4ft 2in
Overall length: 13ft 1in
Overall width:5ft 6.8in
Overall height:4ft 6in
Turning circle: 29.7ft
Kerb weight: 1,796 lbs
Production
Oct 1968 - Dec 1974 1,082,472
4 stud, 12in, pressed steel
Dimensions & Weight
Wheelbase: 7ft 10.5in
Track: 4ft 2in
Overall length: 13ft 1in
Overall width:5ft 6.8in
Overall height:4ft 6in
Turning circle: 29.7ft
Kerb weight: 1,796 lbs
Production
Oct 1968 - Dec 1974 1,082,472
