Ford Anglia E494A 1948-53 Specifications

Engine (8HP)
4 cylinder in-line,
Valves: side, 8, 2 per cylinder
Displacement: 933cc
Bore: 56.6mm
Stroke: 92.5mm
Compression ratio: 6.3 to 1
Carburettors: one
Power output: 23.4bhp at 4,000rpm

Performance
Maximum speed: 59mph
0-50mph: 48.1secs
Fuel: 36mpg

Transmission
3 forward speed manual Rear wheel drive

Construction
Pressed steel body on steel channel chassis

Brakes
Mechanical with 10" drums

Suspension
Front & Rear: Transverse semi-elliptic leaf springs with hydraulic shock absorbers

Steering
Worm and peg

Wheels
17in, 5 stud, bolt-on pressed steel

Dimensions & Weight
Wheelbase: 7ft 6in
Track F: 3ft 7in
Track R: 3ft 7in
Overall length: 12ft 8.2in
Overall width:4ft 7.9in
Overall height: 5ft 4.2in
Ground clearance: 8.8in
Kerb weight: 1,687lbs
Fuel tank 7gals

Production
1948-1953
UK production: 83,751
World total: 387,351
