Triumph Dolomite Sprint 1973-80 classic car portrait print

Page 086

Triumph Dolomite Sprint 1973-80

See specifications below illustration

Triumph Dolomite Sprint 1973-80 specifications

Engine
Slanted 4 cylinder in line
16 valve, single overhead cam
Bore & Stroke: 90.3mm x 78mm
Displacement: 1,998cc
Carburettors: Twin SU HS6
Power output: 127 bhp at 5700rpm

Performance
Maximum speed: 118 mph
Acceleration: 0-60 mph 8.4secs
Overall fuel consumption
approx: 28 mpg

Construction
All steel monocoque

Transmission
Clutch: Borg & Beck single
dry plate
Gearbox: 4-speed,
Laycock J type overdrive

Brakes
Front: disk Rear: drums
Servo assisted

Steering
Rack and pinion

Suspension
Front: independant coil with upper wishbones with lower transverse links with radius rods.
Rear: Coil springs with upper & lower links
Telescopic dampers all round

Wheels & Tyres
13ins ventilated 5.5in alloys
175/70HR13 radials tyres

Dimensions & Capacaties
Wheelbase: 8ft 0.625in
Track - front: 4ft 5.375in
Track - rear: 4ft 2.375in
Overall length:13ft 6in
Overall width: 5ft 1.75in
Overall height: 4ft 3in
Ground clearance: 4.5in
Turning circle: 30ft 4in
Fuel tank capacity: 12.5 gallons
Sump capacity: 8 pints
Kerb weight: 18.56 cwt

Production
1973-1980 22,941

Spot the errors!
For the Sprint enthusiast:
There are various anomalies to the sample above - that's because it is a personalised car drawing albeit with a generic 'years' plate and is typically not 100% original. So if you would like a more accurate drawing of your Sprint please include photographic information with your order in particular showing number plate light, boot badges, front indicators.
(and don't forget you'll receive a proof first)
