See specifications and old advertisment below illustration
Page 011B
Engine
4 cylinder in-line,
8 overhead valves
Displacement: 1,098cc
Bore: 64.6mm
Stroke: 84.7mm
Compression ratio: 8.5 - 1
Valves: 2 per cylinder
Main bearings: 3
Carburettor: Single SU
type HS2
Power output: 48bhp
at 5,100rpm
Performance
Maximum speed: 82.5mph
Acceleration: 0-50 mph 15.7secs
0-60 mph 23.9 secs
Overall fuel consumption:
30.5 mpg
Transmission
4-speed manual,
Syncromesh on 2nd,
3rd & 4th
Rear wheel drive
Construction
Pressed steel monocoque
4 cylinder in-line,
8 overhead valves
Displacement: 1,098cc
Bore: 64.6mm
Stroke: 84.7mm
Compression ratio: 8.5 - 1
Valves: 2 per cylinder
Main bearings: 3
Carburettor: Single SU
type HS2
Power output: 48bhp
at 5,100rpm
Performance
Maximum speed: 82.5mph
Acceleration: 0-50 mph 15.7secs
0-60 mph 23.9 secs
Overall fuel consumption:
30.5 mpg
Transmission
4-speed manual,
Syncromesh on 2nd,
3rd & 4th
Rear wheel drive
Construction
Pressed steel monocoque
Brakes
Hydraulic, Front: drum Rear: drum
Steering
Worm & peg
Suspension
Front: Coil & wishbone
Rear: semi eliptic leaf
Wheels
4 stud, 13in, pressed steel
Dimensions & Weight
Wheelbase: 87.0in
Track front: 47.5in
Track front: 47.0in
Overall length: 146in
Overall width: 59.4in
Overall height: 57.3in
Ground clearance: 6.8in
Kerb weight: 1,757 lbs
Fuel tank: 7gals
A40 Farina Production
1958 -1967
Total production of Mk l &ll
aprox 340,000
Hydraulic, Front: drum Rear: drum
Steering
Worm & peg
Suspension
Front: Coil & wishbone
Rear: semi eliptic leaf
Wheels
4 stud, 13in, pressed steel
Dimensions & Weight
Wheelbase: 87.0in
Track front: 47.5in
Track front: 47.0in
Overall length: 146in
Overall width: 59.4in
Overall height: 57.3in
Ground clearance: 6.8in
Kerb weight: 1,757 lbs
Fuel tank: 7gals
A40 Farina Production
1958 -1967
Total production of Mk l &ll
aprox 340,000
