TVR S 1986-94
See specifications below illustration
Page 240
TVR S V6 1986-94 specifications
Specifications
Engine (Ford Cologne):
60º V6, 12 valve OHV, cast iron block & head, 4 main bearings
Bore & Stroke: 93mm x 68.5mm
Displacement: 2,792cc (170.378 cu in)
Compression ratio: 9.2 / 1
Carburation: Bosch K-Jetronic petrol injection, catalytic converter
Max power: 160bhp at 6,000rpm,
Torque: 162 lbs/ft at 6,000rpm
Max speed: 130mph
0-60mph: 7.6secs
Overall fuel consumption: 27.3mpg(Imp.)
Transmission: RWD, 5-speed manual, all synchro, final drive: 3.64 / 1
Steering: rack and pinion, 2.7 turns lock to lock
Suspension front: ind. unequal length dual wishbones, coil springs, anti-roll bar, rear: coil springs, semi-trailing arms
Brakes: PA, hydraulic, front: ventilated 9.4in disc, rear: 9in drums
Construction: GRP body on multiple tubular steel chassis
Wheels: 15in 8-spoke alloy
Dimensions & Weight
Wheelbase: 90in
Track F: 55in, R: 55in
Overall length: 156in
Overall width: 65.6in
Overall height: 48in
Ground clearance: 5.6
Kerb weight: 2,173 lb
Fuel tank: 11.9 Imp gal
Production: 1986-94 2,604 built (incl. 408 V8 S) produced under the Peter Wheeler ownership. Bamper Bridge, Lancashire, England
