Lotus Elise S2 2001-11
See specifications below illustration
Page 228C
Lotus Elise S2 2001-11 specifications
Production: (all Elise models)
Approx. 30,000 built
Shah Alam, Malayasia and
Hethel, Norfolk UK
Engine:(Rover K Series): Transverse/mid, 4 cylinder inline, DOHC, aluminium block & head, cast iron liners
Bore: 80mm
Stroke: 89.3mm
Displacement: 1,795cc
Compression ratio: 10.5 to one
Carburation: petrol, indirect injection
Max power: 120bhp at 5,500rpm, torque: 124lbs/ft at 4,500rpm
Max speed: 124mph
0-60mph: 5.6secs
O.F.C.: 38.5mpg (Imp.)
Transmission: RWD, 5-speed
Steering: rack and pinion, 32ft 8in turning circle
Suspension: independent, coil & double wishbone front and rear
Brakes: hydraulic PA, ventilated disc front, solid disks rear
Construction: GRP body on aluminium chassis
Tyres: F: 175/55R 16V, R: 225/45 R17
Dimensions
Wheelbase:
90.6in
Track F: 57.4in, R: 59.2in
Overall length: 149in
Overall width: 67in
Overall height: 45in
Ground clearance: 5.5in
Kerb weight: 14.86cwt
Fuel tank: 7 Imp gal
