Ford Escort RS Cosworth Monte Carlo 1992-96
See specifications below illustration
Page 213B
Ford Escort RS Cosworth Monte Carlo 1992-96 specifications
Engine: 4 cyl, 16v DOHC, iron block, alloy head. 5 main bearings, Garett T3/TO4B Turbo, water cooled, catalytic converter
Displacement: 1,993cc
Bore & Stroke: 90.8mm x 76.95mm
Compression Ratio: 8 to 1
Carburation: petrol injection
Power output: 227bhp at 6,250rpm
Torque: 224 lb/ft at 3,500rpm
Maximum speed: 137mph
0-60mph: 5.8secs
OFC: 28.3mpg (Imp.)
Transmission: 5-speed manual, all syncromesh, all wheel drive
Construction: pressed steel monocoque
Drag Coeficient: 0.380
Brakes: Discs F&R, ABS
Steering: rack and pinion, PAS
Suspension Front: Independent MacPherson strut coil, anti roll bar, Rear: Ind. transverse arms. coil
Wheels: 4 stud, 16in x 8J 5 spoke alloy
Dimensions
Wheelbase: 100.5in
Track F: 57.2in, R : 57.9in
Overall length: 165.8in
Overall width: 68.4in
Overall height: 55.8in
Kerb weight: 2,811 lbs
Fuel Tank: 14.3 Imp Gal

Escort RS Cosworth Production
1992-1996: 7,145 built
Monte Carlo: 200 built (70 in RHD), of which this is 058. M636 NWP is one of only 10 in the UK produced in the colour Jewel Violet.
